2027 Diamond C FMAX 212 2.0 ENGINEERE BEAM 25.9K W/HYDRAULIC DOVE TAIL
- No PDI fees
- Warranty available
- Financing available
- Length
- 35′
- Width
- 8′ 6″ (102 in)
- GVWR
- 25,900 lbs
- Axles
- 2
2027 Diamond C FMAX212 2.0 – 35’ Engineered Beam Gooseneck Trailer with Hydraulic Dovetail
Onyx Black | 35’ x 102” | 25.9K GVWR Package | 12’ Hydraulic Dovetail | Tandem 12K Axles with ABS
The 2027 Diamond C FMAX212 2.0 is a premium heavy-duty gooseneck equipment trailer engineered for demanding commercial hauling applications. Featuring Diamond C’s innovative Engineered Beam frame, heavy-duty adjustable suspension, and fully automatic hydraulic dovetail, this 35-foot trailer delivers exceptional strength, versatility, and convenience for transporting heavy equipment, machinery, vehicles, and commercial loads.
Finished in sleek Onyx Black, this FMAX212 is loaded with premium factory-installed equipment, including tandem 12,000 lb axles with anti-lock brakes (ABS), dual 20,000 lb hydraulic jacks, a 12-foot fully automatic hydraulic dovetail, and a heavy-duty 30K CURT gooseneck coupler.
Whether you’re hauling construction machinery, agricultural equipment, trucks, or commercial loads, this trailer is built to handle serious work.
Key Features & Highlights
35’ x 102” Deck-Over Design – Expansive loading surface for heavy equipment, vehicles, and oversized loads.
25.9K GVWR Configuration – Heavy-duty trailer package designed for demanding hauling applications.
Engineered Beam Frame – Diamond C’s innovative structural design with 3” I-beam crossmembers on 16” centers.
12’ Fully Automatic Hydraulic Dovetail – Convenient hydraulic loading system eliminates the need to manually position traditional loading ramps.
Full Steel Dovetail Runners with Cleats – Heavy-duty steel loading surface designed to provide traction for equipment.
Tandem 12,000 LB Axles with ABS – Electric drum brakes with anti-lock braking technology for improved braking control.
Heavy-Duty Adjustable Suspension – Designed for dependable load support and trailer performance.
Dual 20,000 LB Hydraulic Jacks – Powerful hydraulic landing gear makes hitching and unhitching easier.
30K CURT Gooseneck Coupler – Heavy-duty square coupler designed for a 2-5/16” hitch ball.
12” Engineered Gooseneck – Robust gooseneck construction for heavy-duty towing applications.
2” Treated Wood Flooring – Durable deck surface for equipment and commercial hauling.
Gooseneck Winch Mounting Tray – Integrated winch mounting location for additional loading versatility.
Retractable Under-Frame Spare Mount – Cable winch-style spare tire mount for convenient access.
Heavy-Duty Underslung Storage Box – 14” x 14” x 42” storage compartment for tools and equipment.
17.5” 18-Ply Dual Tires – Heavy-duty ST215/75R17.5 radial tires with aluminum outer wheels.
Matching Spare Tire – ST215/75R17.5 18-ply radial spare with black steel wheel.
SolarPulse Charging System – 7-watt solar charging system helps maintain the Group 27 battery.
All-LED Lighting – LED lighting package for dependable visibility.
Sway Control Pipe – Factory-installed provision for compatible sway-control equipment.
Factory Specifications
Year: 2027
Manufacturer: Diamond C Trailers
Model: FMAX212 2.0 HDT
Trailer Type: Engineered Beam Gooseneck Equipment Trailer
Configuration: 25.9K GVWR Package
Deck Length: 35’
Deck Width: 102”
Dovetail: 12’ Fully Automatic Hydraulic
Dovetail Surface: Full Steel Runners with Cleats
Exterior Color: Onyx Black
Axles: Tandem 12,000 LB
Brakes: Electric Drum with ABS
Suspension: Heavy-Duty Adjustable
Frame: Engineered Beam
Crossmembers: 3” I-Beam on 16” Centers
Gooseneck: 12” Engineered Neck
Coupler: 30K CURT, 2-5/16” Ball
Jacks: Dual 20K Hydraulic
Flooring: 2” Treated Wood
Winch Provision: Gooseneck Winch Mounting Tray
Storage: 14” x 14” x 42” Underslung Box
Tires: ST215/75R17.5 Dual, 18-Ply Radial
Wheels: Aluminum Outer Wheels
Spare: ST215/75R17.5 Dual, 18-Ply Radial, Black Steel Wheel
Battery: Group 27
Charging System: 7-Watt SolarPulse
Dovetail Charger: 5-Amp
Lighting: All LED
Maximum Capability. Premium Diamond C Engineering.
The 2027 Diamond C FMAX212 2.0 is built for professionals who demand exceptional hauling capability without sacrificing convenience. Its advanced Engineered Beam frame, 12-foot fully automatic hydraulic dovetail, and heavy-duty tandem 12K axles make it an excellent choice for commercial equipment transport.
Premium features like dual hydraulic jacks, ABS braking, heavy-duty adjustable suspension, and oversized storage make this trailer a serious investment in productivity.
Finished in Onyx Black, this FMAX212 combines rugged capability with Diamond C’s renowned engineering and craftsmanship.
Specifications
- Type
- Tilt Deck
- Stock No
- V1317564
- Condition
- New
- Length
- 35′
- Width
- 8′ 6″ (102 in)
- Axles
- 2
- Weight
- 8,940 lbs
- GVWR
- 25,900 lbs
- Make
- Diamond C
- Model
- FMAX 212 2.0
- Year
- 2027
- Location
- Anderson Sales and Service
