The Wells Cargo Road Force® V-Front is a feature-rich enclosed cargo trailer designed for dependable everyday hauling with the distinctive styling and added functionality of a V-front design. Built for work, recreation, equipment, motorcycles, tools, and general cargo, the Road Force V-Front combines rugged construction with practical features and a wide range of available sizes.
The V-front design distinguishes this model from the standard Road Force radius-front cargo trailer while providing a distinctive profile and additional usable space toward the front of the trailer.
Built around a durable tubular steel structure, the Road Force V-Front features 16” on-center floor crossmembers, vertical posts, and roof structure for a strong foundation. High-performance PlexCore® decking and interior sidewalls, a bonded aluminum composite exterior, one-piece aluminum roof, and protective undercoating contribute to a trailer designed for long-term use.
Available in multiple 5’, 6’, and 7’ wide configurations with both single- and tandem-axle models, the Wells Cargo Road Force V-Front provides a versatile enclosed hauling solution with the construction, cargo access, and equipment needed for demanding everyday use.
Road Force Features
Distinctive V-Front Design
The Road Force V-Front features Wells Cargo’s V-front profile, distinguishing it from the standard Road Force radius-front cargo trailer while providing additional usable space at the front of the cargo area.
16” On-Center Construction
Floor crossmembers, tubular vertical posts, and tubular roof structure are positioned 16” on center to create a strong structural foundation.
Bonded Aluminum Composite Exterior
Bonded .080 aluminum composite exterior panels provide a clean exterior appearance while eliminating exposed exterior fasteners across the body panels.
PlexCore® Interior Construction
High-performance 3/4” PlexCore® interior decking and 3/8” PlexCore® interior sidewalls provide durable surfaces for everyday cargo use.
One-Piece Aluminum Roof
A one-piece aluminum roof provides durable overhead protection while minimizing roof seams.
Rear Ramp Door with Spring Assist
Most Road Force V-Front models include a rear ramp door with spring assist for convenient loading and unloading. The 5’ x 8’ configuration uses a rear swing door.
16” Ramp Extension
A ramp extension provides a smoother transition when loading equipment and cargo through the rear ramp door.
36” Side Entry Door
Most configurations include a 36” side entry door with a flush lock for convenient access to the cargo area.
24” ATP Stoneguard
Aluminum tread plate stoneguard helps protect the lower front of the trailer against rocks and road debris.
Undercoated Chassis
The entire chassis is undercoated to provide additional protection from road exposure and the elements.
ArmorTech™ Protection
ArmorTech™ is applied to the A-frame and rear end rail for additional protection in areas regularly exposed to road conditions.
Spring Axles with E-Z Lube® Hubs
Spring axles and E-Z Lube® hubs provide dependable running gear with convenient access for routine bearing maintenance.
Radial Tires
15” radial tires with silver spoke wheels are standard equipment.
LED Lighting
LED slim-line tail lights, heavy-duty LED clearance lights, and a 12-volt LED interior dome light provide efficient exterior and interior illumination.
Flow-Through Ventilation
Flow-through sidewall vents promote air circulation through the enclosed cargo area.
Single & Tandem Axle Configurations
Road Force V-Front models are available in both single- and tandem-axle configurations, allowing buyers to select the size and capacity that best fits their hauling requirements.
3-Year Limited Warranty
Road Force V-Front trailers are backed by Wells Cargo’s 3-year limited warranty.
ROAD FORCE V-FRONT 5’, 6’ & 7’ WIDE SPECIFICATIONS
5’ x 8’ — RFV58S2
- Body Length: 9’6”
- Body Width: 5’0”
- Overall Length: 11’6”
- Overall Width: 6’8”
- Overall Height: 7’2”
- Interior Length: 9’1”
- Interior Width: 4’9”
- Interior Height: 5’6”
- Platform Height: 17”
- Axles: Single
- Total Axle Capacity: 3,500 lbs.
- GVWR: 2,990 lbs.
- Approx. Curb Weight: 975 lbs.
- Approx. Payload Capacity: 2,015 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2”
- Brakes: N/A
6’ x 10’ — RFV610S2
- Body Length: 11’6”
- Body Width: 6’0”
- Overall Length: 14’0”
- Overall Width: 7’8”
- Overall Height: 8’1”
- Interior Length: 11’3”
- Interior Width: 5’9”
- Interior Height: 6’6”
- Platform Height: 17”
- Axles: Single
- Total Axle Capacity: 3,500 lbs.
- GVWR: 2,990 lbs.
- Approx. Curb Weight: 1,195 lbs.
- Approx. Payload Capacity: 1,795 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2”
- Brakes: Optional
6’ x 12’ Single Axle — RFV612S2
- Body Length: 13’6”
- Body Width: 6’0”
- Overall Length: 16’0”
- Overall Width: 7’8”
- Overall Height: 8’1”
- Interior Length: 13’3”
- Interior Width: 5’9”
- Interior Height: 6’6”
- Platform Height: 17”
- Axles: Single
- Total Axle Capacity: 3,500 lbs.
- GVWR: 2,990 lbs.
- Approx. Curb Weight: 1,325 lbs.
- Approx. Payload Capacity: 1,665 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2”
- Brakes: Optional
6’ x 12’ Tandem Axle — RFV612T2
- Body Length: 13’6”
- Body Width: 6’0”
- Overall Length: 16’0”
- Overall Width: 7’8”
- Overall Height: 8’2”
- Interior Length: 13’3”
- Interior Width: 5’9”
- Interior Height: 6’6”
- Platform Height: 18”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 1,740 lbs.
- Approx. Payload Capacity: 5,260 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
7’ x 12’ Tandem Axle — RFV712T2
- Body Length: 13’6”
- Body Width: 7’0”
- Overall Length: 16’0”
- Overall Width: 8’6”
- Overall Height: 8’2”
- Interior Length: 13’3”
- Interior Width: 6’9”
- Interior Height: 6’6”
- Platform Height: 18”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 1,975 lbs.
- Approx. Payload Capacity: 5,025 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
7’ x 14’ Tandem Axle — RFV714T2
- Body Length: 15’6”
- Body Width: 7’0”
- Overall Length: 18’0”
- Overall Width: 8’6”
- Overall Height: 8’2”
- Interior Length: 15’3”
- Interior Width: 6’9”
- Interior Height: 6’6”
- Platform Height: 18”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 2,125 lbs.
- Approx. Payload Capacity: 4,875 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
7’ x 16’ Tandem Axle — RFV716T2
- Body Length: 17’6”
- Body Width: 7’0”
- Overall Length: 20’0”
- Overall Width: 8’6”
- Overall Height: 8’2”
- Interior Length: 17’3”
- Interior Width: 6’9”
- Interior Height: 6’6”
- Platform Height: 18”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 2,275 lbs.
- Approx. Payload Capacity: 4,725 lbs.
- Tire Size: ST205/75R15
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
ROAD FORCE V-FRONT 8.5’ WIDE SPECIFICATIONS
8.5’ x 16’ — RFV8516T2
- Body Length: 17’10”
- Body Width: 8’4”
- Overall Length: 19’6”
- Overall Width: 8’6”
- Overall Height: 8’7”
- Interior Length Including V: 17’6”
- Interior Width: 8’0”
- Interior Height: 6’6”
- Width Between Wheel Boxes: 83”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 2,580 lbs.
- Approx. Payload Capacity: 4,420 lbs.
- Rear Ramp Opening: 94” x 72”
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
- Beavertail: Optional
8.5’ x 20’ — RFV8520T2
- Body Length: 21’10”
- Body Width: 8’4”
- Overall Length: 23’6”
- Overall Width: 8’6”
- Overall Height: 8’7”
- Interior Length Including V: 21’6”
- Interior Width: 8’0”
- Interior Height: 6’6”
- Width Between Wheel Boxes: 83”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 3,220 lbs.
- Approx. Payload Capacity: 3,780 lbs.
- Rear Ramp Opening: 94” x 75”
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
- Beavertail: 48”
8.5’ x 24’ — RFV8524T2
- Body Length: 25’10”
- Body Width: 8’4”
- Overall Length: 27’6”
- Overall Width: 8’6”
- Overall Height: 8’7”
- Interior Length Including V: 25’6”
- Interior Width: 8’0”
- Interior Height: 6’6”
- Width Between Wheel Boxes: 83”
- Axles: Tandem
- Total Axle Capacity: 7,000 lbs.
- GVWR: 7,000 lbs.
- Approx. Curb Weight: 3,860 lbs.
- Approx. Payload Capacity: 3,140 lbs.
- Rear Ramp Opening: 94” x 75”
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
- Beavertail: 48”
8.5’ x 28’ — RFV8528T3
- Body Length: 29’10”
- Body Width: 8’4”
- Overall Length: 31’6”
- Overall Width: 8’6”
- Overall Height: 8’8”
- Interior Length Including V: 29’6”
- Interior Width: 8’0”
- Interior Height: 6’6”
- Width Between Wheel Boxes: 83”
- Axles: Tandem
- Total Axle Capacity: 10,400 lbs.
- GVWR: 9,990 lbs.
- Approx. Curb Weight: 4,680 lbs.
- Approx. Payload Capacity: 5,310 lbs.
- Rear Ramp Opening: 94” x 75”
- Hitch Ball Size: 2-5/16”
- Brakes: Electric Drum with Breakaway Kit
- Beavertail: 48”
Specifications, dimensions, weights, capacities, and equipment are subject to change by the manufacturer. Actual specifications and payload capacity may vary based on trailer configuration and installed options.
